Max. 5 MHz, 8-axis pulse output
Encoder input is 10 MHz for 4xAB mode, 2.5 MHz for CW/CCW mode
BoardID is switchable
Easily visible LED indicators on board to do diagnosis
Direct wire to servo drive to save terminal board space while installation
Horizontal installation for for servo or stepping motor driver
Suitable for DIN-rail mounting
Programmable interrupt
Memory buffer (10K points) for trajectory planning which is designed in DSP
2-axis position compare triggering up to 100 KHz, and memory buffer is up to 100 K points
Position latch
Supports gantry mode by semi-closed loop pulse train control
RDY/LTC-dedicated input channels & SVON/CMP/CAM-DO/ERC-dedicated
Output channels are switchable for general input and output purposes
